July 2019
2-9
Xerox® B210 Service Manual
08-100 , 08-500
Status Indicator RAPs
Initial Release
08-100 Paper Feed Fault - Tray 1 RAP
BSD-ON:BSD 1
The lead edge was not detected by the Feed Sensor.
Initial Actions
Clear any jammed sheets. Refer to Section 7: Troubleshooting, in the Xerox® B210 User
Guide for detailed instructions on clearing paper jams.
Procedure
Check the Feed Sensor Actuator for damage or binding. The Actuator moves freely.
YN
Install a new Feed Sensor Actuator, P
L 4.4 Item 18.
Check the position of the jammed sheet. The lead edge reached the Retard Roll.
YN
• Check the circuit between the Feed clutch and the Main PWB for an open or short
ci
rcuit.
• Install a new Feed Clutch, PL 4.
1 Item 5.
Check the Feed Sensor Actuator. The actuator moves freely.
YN
Install a new Feed Sensor Actuator, P
L 4.4 Item 18.
Check the new Feed Sensor. The signal changes.
YN
• Verify there is no contamination or damage
on any connectors from the Feed Sensor
PW
B to the HVPS PWB. Repair as necessary.
• Install a new Feed Sensor PWB, PL 4.
4 Item 20.
Perform SCP 4 Final Actions.
If the problem is intermittent check the cables for binding.
08-500 Paper Jam in Exit Area RAP
BSD-ON:BSD 1
The machine has detected a paper jam in the Exit Area.
Initial Actions
Open the Rear Cover and remove jammed sheets from exit area. Refer to Section 7: Trouble-
shooting, in the Xerox® B210 User Guide for detailed instructions on clearing paper jams.
Check the Paper Guides for proper position.
Check the Duplex Gate and Spring for damage. Ensure that the gate is seated correctly and
mo
ves freely without binding.
Procedure
Check for obstruction to unblock and clear the Exit Sensor. The Exit Sensor is OK.
YN
• Verify there is no contamination present.
• Check for an open or short circuit.
• Install a new Exit Sensor, PL 4.
5 Item 3.
Check for obstruction to unblock and clear the Registration Sensor. The signal changes.
YN
• Verify there is no contamination present.
• Check for an open or short circuit.
• Install a new Feed Sensor PWB, PL
4.4 Item 20.
Inspect the Exit Roll for wear or damage. If the Exit Roll is damaged or shows excessive wear,
install a new Exit Roll, PL 4.3 Item 5.
To Next Page
