July 2019
2-8
Xerox® B210 Service Manual
07-500 , 07-530
Initial Release
Status Indicator RAPs
07-500 Manual Feed Slot Paper Empty RAP
BSD-ON:BSD 1
The Registration Sensor failed to detect paper in the Manual Feed Slot.
Initial Actions
Ensure that paper is loaded in the tray. Clear any jammed sheets. Refer to Section 7: Trouble-
shooting, in the Xerox® B210 User Guide for detailed instructions on clearing paper jams.
Procedure
Check the Registration Sensor actuator. The actuator moves freely and is undamaged.
YN
• Verify no contamination is present.
• Install a new Registration Sensor Actuator, P
L 4.4 Item 19.
The sensor signal changes.
YN
Check for 3.3 VDC on the Main PWB. The voltage is present on the Main PWB.
YN
• Install a new HVPS PWB, PL 4.
1 Item 2.
• Install a new Main PWB, PL 1.1 Item 7.
Install a new Feed Sensor PWB, PL 4.4 Item 20.
Perform SCP 4 Final Actions.
07-530 Paper Feed Fault - Manual Feed Slot RAP
BSD-ON:BSD 1
The lead edge was not detected by the Paper Feed Sensor.
Initial Actions
Clear any jammed sheets. Refer to Section 7: Troubleshooting, in the Xerox® B210 User
Guide for detailed instructions on clearing paper jams.
Procedure
Check the position of the jammed sheet. The lead edge reached the Retard Roll.
YN
• Check for an open or short circuit.
• Install a new Feed Sensor, PL 4.
4 Item 20.
Check the feed again. The clutch engages.
YN
• Check for an open or short circuit.
• Install a new Feed Clutch, PL 4.
1 Item 5.
Perform SCP 4 Final Actions.
Check the Paper Feed actuator. The actuator moves freely and is undamaged.
YN
Install a new Feed Sensor Actuator, P
L 4.4 Item 18.
Inspect the Feed Sensor for damage. The sensor is OK.
YN
• Check for an open or short circuit.
• Install a new Feed Sensor PWB, PL
4.4 Item 20.
Check the circuit of the Feed Sensor PWB.
To Next Page
