15 Maintenance
308 Xerox CopyCentre/WorkCentre/WorkCentre Pro 123/128/133 User Guide
Inserting the New Drum Cartridge
1. Remove the new drum cartridge from the box.
2. Carefully remove the protective
sheet from the cartridge by
picking the sealing tape up.
3. Place the cartridge in position as
shown and slide it into the
machine until it clicks.
4. Pull out the cartridge tape
straight without breaking it.
5. Push the cartridge again to
ensure it is positioned correctly.
To Next Page
