Xerox Phaser 3140 Service Manual

5-12 Phaser 3140/3155/3160 Printer Service Manual
Print-Quality Troubleshooting
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the connectors between the
Controller Board and Power Supply
Board.
Are the connectors secure?
Go to step 3. Reconnect the
connectors.
Go to step 2.
2 Does the error still occur? Go to step 3. Complete.
3 Replace the Power Supply Board
(page 8-54).
Does the error still occur?
Go to step 4. Complete.
4 Does the error still occur? Replace the
Laser Unit
(page 8-30).
Go to step 5.
Complete.
5 Does the error still occur? Replace the
Controller
Board
(page 8-51).
Complete.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
