Phaser 3140/3155/3160 Printer Service Manual 8-29
Service Parts Disassembly
Disassembly Procedures
Tray Holder Pad Assembly
PL10.0.11
1. Remove the Tray (page 8-7).
2. Remove paper from the Tray.
3. Unhook the latches on the left and right sides of the Holder Pad and remove
it.
