Xerox Phaser 3140 Service Manual

Phaser 3140/3155/3160 Printer Service Manual 3-15
Error Messages and Codes
Paper Tray Empty With No Indication
The Status LED does not indicate when the Tray is empty.
Initial Actions
• Check the paper path for obstructions or debris.
• Cycle printer power.
• If the problem persists, refer to the following procedure.
3 Replace the Power Supply Board.
Does the problem persist?
Replace the
Controller
Board
(page 8-51).
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Paper Tray Empty Actuator,
PL6.0.56
■ Power Supply Board, PL1.0.1
■ Controller Board, PL1.0.2
■ 3140 Power Supply Wiring
■ 3155 Power Supply Wiring
■ 3160 Power Supply Wiring
■ Map 4 - 110V and 220V Power Supply
Boards
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Paper Tray Empty
Actuator for damage.
Is the actuator damaged?
Repair or
replace the
actuator
(page 8-47).
Go to step 2.
2 Check the continuity of the harness
connecting the Power Supply Board
CON2 and the Controller Board CN5
(CN7 on the 3160).
Is the harness damaged?
Repair the
harness.
If the problem
persists, go to
step 3.
Go to step 3.
3 Replace the Power Supply Board
(page 8-54).
Does the problem persist?
Go to step 4. Complete.
4 Replace the Controller Board
(page 8-51).
Complete.
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
