Phaser 3140/3155/3160 Printer Service Manual 8-13
Service Parts Disassembly
Thermistor
PL9.0.11
Turn the printer power Off and allow the Fuser to cool 30 minutes before
performing this procedure.
1. Remove the Fuser (page 8-11).
2. Remove 1 screw (10 mm, silver, tap) securing the Thermistor.
3. Remove the wiring harness from the harness guide and remove the
Thermistor.
s3160-056
