8-20 Phaser 3140/3155/3160 Printer Service Manual
Service Parts Disassembly
Pressure Roller
PL9.0.34
Turn the printer power Off and allow the Fuser to cool 30 minutes before
performing this procedure.
1. Remove the Fuser (page 8-11).
2. Remove the Heat Roller (page 8-17).
3. Rotate the Right Bushing counter-clockwise and then remove it.
