Xerox Phaser 3140 Service Manual

Phaser 3140/3155/3160 Printer Service Manual 5-13
Print-Quality Troubleshooting
Uneven Density
Print density is uneven between the left and right sides. Possible causes include;
uneven spring force at the ends of the Transfer Roller, the springs are damaged,
the Transfer Roller is improperly installed, or the Transfer Roller bushing or holder is
damaged.
Initial Actions
• Check the paper transfer path.
• Ensure there is no debris in the transfer path.
Troubleshooting Reference Table
Applicable Parts Example Print
■ Transfer Roller, PL1.0.8
■ Print Cartridge, PL1.0.12
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Transfer Roller
installation. Reseat the Transfer
Roller if necessary (page 8-8).
Does the image quality improve?
Complete. Go to step 2.
2 Check the Print Cartridge.
Is the Print Cartridge empty or
damaged?
Replace the
Print Cartridge
(page 8-6).
Complete.
Color Uneven or Wrong (Process Direction)
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
