Xerox Phaser 3140 Service Manual

Phaser 3140/3155/3160 Printer Service Manual 3-23
Error Messages and Codes
Front Cover Errors
Error Indicated When Front Cover is Closed
The Status LED indicates an error even though the Front Cover is closed.
Initial Actions
• Cycle printer power.
• If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Front Cover, PL1.0.11
■ Power Supply Board, PL1.0.1
■ Map 5 - Sensors
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check that the Front Cover open
actuator (PL6,0.55) is securely
affixed to the frame.
Is the actuator firmly attached?
Go to step 2. Tighten the
actuator screw.
If the problem
persists, go to
step 2.
2 Inspect the Front Cover for damage.
Is the Front Cover damaged?
Replace the
Front Cover.
If the problem
persists, go to
step 3.
Go to step 3.
3 Replace the Power Supply Board
(page 8-54).
Complete.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
