Xerox Phaser 3140 Service Manual

A-2 Phaser 3140/3155/3160 Printer Service Manual
Reference
Acronyms and Abbreviations
Acronym Description
A3 Paper size 297 millimeters (11.69 inches) x 420 millimeters (16.54
inches).
A4 Paper size 210 millimeters (8.27 inches) x 297 millimeters (11.69 inches).
A5 Paper size 148 millimeters (5.82 inches) x 210 millimeters (2.10 inches).
AC Alternating Current is type of current available at power source for the
printer.
AMPV Average Monthly Print Volume
ASIC Application Specific Integrated Circuit
ASSY Assembly
BIOS Basic Input Output System
BOOTP Boot Parameter Protocol
BSD Block Schematic Diagram
BTM Bottom
CAM Cam Shaft
CCD Charged Coupled Device (Photoelectric Converter)
CD Compact Disc
CLT Clutch
CMOS Complementary Metal Oxide Semiconductor
CN Connector
CON Connector
CPU Central Processing Unit
CRU Customer Replaceable Unit
CRUM Customer Replaceable Unit Meter/Memory
CST Cassette
dB Decibel
dbA decibel ampere
dBM decibel milliwatt
DAA Data Access Arrangement
DC Direct Current is type of power for printer components. Machine converts
AC power from power source to DC power.
DCU Diagnostic Control Unit
DDR2
DIMM
Double Data Rate Dual In-Line Memory Module
DEVE Developer
DHCP Dynamic Host Configuration Protocol
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
