Xerox Phaser 3140 Service Manual

1-2 Phaser 3140/3155/3160 Printer Service Manual
General Information
Introduction and Overview
The Xerox Phaser 3140/3155/3160 Printers have a single-pass laser design
architecture,. Print speeds range between 18 and 24 pages per minute (ppm), and
resolution up to 1200 x 1200 dots-per-inch (dpi) image quality depending on the
model.
The Phaser 3140/3155/3160 provides a standard 250-Sheet, input tray. The
manual feeder holds 1 sheet. The manual feeder supports specialty media, card
stock, and envelopes. The output tray holds 100 sheets facedown.
Technical Support Information
The Xerox Phaser 3140/3155/3160 Printer Service Manual is the primary
document used for repairing, maintaining, and troubleshooting the printers.
To ensure complete understanding of this product, participation in Xerox Phaser
3140/3155/3160 Printer Service Training is strongly recommended.
For updates to the Service Manual, Service Bulletins, knowledge base, etc., go to:
• Xerox Global Service Net: https://www.xrxgsn.com/secure/main.pl
• Service Partners: http://www.office.xerox.com/partners
For further technical support, contact your assigned Xerox Technical Support for
this product.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
