10-2 Phaser 3140/3155/3160 Printer Service Manual
Wiring
Plug/Jack Locators
The Plug/Jack Locator diagrams show the P/J locations within the printer. Use
these illustrations to locate connections called out in the Troubleshooting
procedures presented in Sections 3, 4, and 5.
1. Locate the P/J connector designator in the first column of the table.
2. With this information, go to the map listed in the second column.
3. Use the coordinates to locate the connection indicated on the map with its P/
J designation number.
4. The Description column provides a brief description of each connection.
Controller Board and Power Supply Plug/Jack Designators and Locator
P/J Map Coordinates Description
3140 Controller Board
CN1 1 C-137 N/A
CN2 1 F-140 Out Bin Full Sensor
CN3 1 B-137 N/A
CN4 1 J-139 Laser Unit
CN5 1 J-137 Power Supply
CN6 1 A-138 USB Port
CN7 1 I-139 Pick Up Solenoid
CN8 1 J-140 Control Panel
CN9 1 H-139 Print Cartridge CRUM
CN11 1 G-140 Motor/Manual Solenoid
CN12 1 E-140 Fuser Thermistor
3155 Controller Board
CN1 2 C-137 N/A
CN2 2 B-137 Out Bin Full Sensor
CN4 2 J-139 Laser Unit
CN5 2 K-138 Power Supply
CN6 2 F-140 Motor/Manual Solenoid
CN7 2 J-140 Pick Up Solenoid
CN8 2 G-140 Control Panel
CN9 2 I-140 Print Cartridge CRUM
CN11 2 A-138 USB Port
CN12 2 D-140 Fuser Thermistor
3160B and 3160N Controller Board
CN1 3 C-137 N/A
CN2 3 B-137 N/A
CN3 3 A-138 USB Port
CN4 3 A-139 Ethernet Port (3610N only)
CN5 3 J-139 Laser Unit
CN6 3 J-140 Pick Up Solenoid
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
