Phaser 3140/3155/3160 Printer Service Manual 2-17
Theory of Operation
Exit Sensor
The Exit Sensor, located on the Fuser, detects the media as it exits the Fuser.
The CPU monitors the on/off timing of the Exit Sensor signal and determines
normal operation or the presence of a jam (Jam2). If a paper jam is detected, the
red LED on the Control Panel illuminates.
Out Bin Full Sensor
The Out Bin Full Sensor detects when the output tray is full If the sensor detects
the output tray is full, the red LED on the Control Panel illuminates.
Front Cover Interlock
The Front Cover Interlock switch is located on the Power Supply. When the Front
Cover is open, the +24 V that is supplied to the Motor, solenoids, Fan, Laser Unit,
and the high voltage circuitry is cut off. When the Front Cover is open, the Status
LED changes to red.
Driving Circuit
Fan and Solenoid Driving
The Fan, Pick Up Solenoid, and the Manual Feed Solenoid are driven by signals
from the Controller Board. A diode protects the driving transistor from the noise
pulse that is created when the solenoid is de-energizing.
Motor Driving
The Controller Board contains the motor interface circuits, and the Drive Assembly
contains a motor control board with a driver IC.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
