Phaser 3140/3155/3160 Printer Service Manual 8-9
Service Parts Disassembly
Pick Up Roller
PL8.0
1. Remove the Paper Tray.
2. Turn the printer over.
3. Remove 1 screw (silver, 6 mm, plastic, tap).
4. Use a flat screwdriver to carefully lift the tab off of the Pick Up Roller.
