Phaser 3140/3155/3160 Printer Service Manual 3-17
Error Messages and Codes
Out Bin Full
The red Error LED is blinking.
Initial Actions
• Check the Out Bin Full Actuator for damage or obstructions.
• Cycle printer power.
• If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ To p Co ver, PL2. 0
■ Controller Board, PL1.0.2
■ Out Bin Full Sensor, PL6.0.73
■ 3140 Controller Board Wiring
■ 3155 Controller Board Wiring
■ 3160 Controller Board Wiring
■ Map 1 - Controller Board (3140)
■ Map 2 - Controller Board (3155)
■ Map 3 - Controller Board (3160B/
3160N)
■ Map 5 - Sensors
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Remove the Top Cover (page 8-23),
and check the Output Bin Full
Actuator for damage.
Is the actuator damaged?
Repair the
actuator if
possible, or
replace the Top
Cover
(page 8-23). If
the problem
persists, go to
step 2.
Go to step 2.
2 On the Controller Board check for
+3.3 V at CN2-1 (CN15-1 on printer
model 3160).
Is +3.3 V present?
Go to step 3. Replace the
Controller
Board
(page 8-51). If
the problem
persists, go to
step 3.
3 Check the continuity of the bin full
harness connecting the Controller
Board and Out Bin Full Sensor.
Is the harness damaged?
Repair the
harness.
Replace the
Out Bin Full
Sensor
(page 8-63).
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
