Xerox Phaser 3140 Service Manual

3-16 Phaser 3140/3155/3160 Printer Service Manual
Error Messages and Codes
Multiple Sheet Feeding
Multiple sheets of media are fed at the same time.
Initial Actions
1. Remove, fan, and reload the media. Ensure that the tray has not been over
filled.
2. Try loading paper from a fresh ream, fan the paper, and then insert into the
tray or flip existing paper over.
3. Cycle printer power.
If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Paper Tray Holder Pad Assembly,
PL10.0.11
■ Pick Up Solenoid, PL4.0.37
■ Map 6 - Motor, Solenoids, and Fan
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the left and right paper
guides of the Paper Tray to ensure
they are set correctly.
Are the paper guides set correctly?
Go to step 2. Adjust the left
and right
paper guides.
2 Check the Paper Tray Holder Pad.
Is the Holder Pad dirty or damaged?
Clean the
Holder Pad, and
replace if
necessary
(page 8-29). If
the problem
persists, go to
step 3.
Go to step 3.
3 Replace the Pick Up Solenoid
(page 8-61).
Complete.
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
