Phaser 3140/3155/3160 Printer Service Manual 8-21
Service Parts Disassembly
4. Rotate the Left Bushing clockwise and then remove it.
5. Release the e-ring and washer that secures the Jam Link Lever, and then
remove the Jam Link Lever.
You can remove the e-ring/washer from either the left or right lever.
