Phaser 3140/3155/3160 Printer Service Manual 8-31
Service Parts Disassembly
4. Lift the Laser Unit slightly, and disconnect CN1 and CN5.
5. Remove the Laser Unit.
Downloaded From ManualsPrinter.com Manuals
