Phaser 3140/3155/3160 Printer Service Manual 9-5
Parts List
Parts List 1.0 Main
ID No. Name/Description Part Number
1. Power Supply Board, 110V
Power Supply Board, 220V
105N02172
105N02173
2. Controller Board
3140
3155
3160B
3160N
140N63413
140N63414
140N63415
140N63411
3. Paper Tray 050N00547
4. Power Inlet Bracket
5. Engine Shield
6. Engine Harness
7. Fuser - 110V
Fuser - 220V
126N00332
126N00333
8. Transfer Roller 022N02354
9. Main Frame
10. Top Cover 002N02909
11. Front Cover
3140
3155
3160B
3160N
002N02910
002N02911
002N02912
002N02906
12. Print Cartridge - 1.5K
Print Cartridge - 2.5K
108R00908
108R00909
13. Power Cord, 110V
Power Cord, 220V
105N02072
117N01769
