Phaser 3140/3155/3160 Printer Service Manual 9-23
Parts List
Parts List 7.1 Drive Assembly (Models 3155/3160)
ID No. Name/Description Part Number
0. Drive Assembly 030N00770
1. Bracket P Gear 1400 —
2. Motor BLDC —
3. Bracket Motor Step —
4. Gear RDCN OPC —
5. Gear RDCN 57/18 —
6. Gear RDCN 90/31 —
7. Gear RDCN 103/41 —
8. Gear DRV Fuser Out —
9. Gear Hub Clutch —
10. Gear DRV Fuser In —
11. Gear Fuser DR OUT 37 —
12. Gear Hub Clutch —
13. Gear DRV Fuser In —
14. Screw-Taptype —
15. Plain Washer —
