8-12 Phaser 3300MFP Service Manual
Service Parts Disassembly
5. Remove two screws, then the Fuser Harness Connector.
6. Unplug the thermistor harness from the Fuser Harness Connector.
Remove one screw then the Thermistor.
s3300mfp-019
Input Guide
s3300mfp-020
Thermistor
