8-30 Phaser 3300MFP Service Manual
Service Parts Disassembly
3. Unplug the three connectors from the Control Panel PBA, as shown
below.
4. Remove the nine screws securing the Control Panel PBA to the Control
Panel Cover.
s3300mfp-035
Control Panel Cover
Control Panel Board
LCD
Cover
