8-42 Phaser 3300MFP Service Manual
Service Parts Disassembly
2. Pull up the Feed Idle Shaft and the Bushings (with Spring).
3. Release the E-Ring securing the Feed2 Gear and remove it.
Feed Idle Shaft
Bushing
Spring
s3300mfp-136
