9-14 Phaser 3300MFP Service Manual
Parts List
3-8 FIXER-M_E RING 4PI —
3-9 MEA-ROLLER PICK UP 022N02292
3-9-1 ROLLER-IDLE PICK UP —
3-9-2 HOUSING-M_PICK UP —
3-9-3 ROLLER-PICK UP —
3-10 SHAFT-PICK UP —
3-11 PMO-BUSHING_P/U, MP —
3-12 CAM-CATCH 003N00867
3-13 ROLLER-FEED 022N02293
4 SHAFT-FEED IDLE —
5 BUSH-M-FEED IDLE —
6 FEED1 ASS'Y —
6-1 HOLDER-M_ACT REGI —
6-2 SPRING-TS —
6-3 LEVER-M_ACTUATOR FEED —
6-4 LEVER-M_ACTUATOR REGI —
7 FEED2 ASS'Y —
7-1 HOLDER-M_ACT FEED —
7-2 LEVER-M_ACT DUP OUT —
7-3 SPRING-TS —
8 MEA UNIT-CLUTCH 005N01031
8-1 SHAFT-FEED —
8-2 PMO-HUB CLUTCH —
8-3 SPRING-TS —
8-3 SPRING-TS —
8-4 PMO-COLLAR_SPRING —
8-5 GEAR-FEED 1 —
9 MEA UNIT-BRACKET FEED —
9-1 BRACKET-P-FEED —
9-2 GEAR-IDLE Z29 HELICAL —
9-3 RING-E —
9-4 GEAR-RETARD 39/19 —
9-5 RING-E —
9-6 GEAR-T2 IDEL_Z27 —
10 MEA UNIT-GEAR PICK UP —
Parts List 6.0 Frame (continued)
ID No. Name/Description
Part Number

Xerox Phaser 3300 Specifications

General

Print Technology	Laser
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Automatic Document Feeder	50 sheets
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Connectivity	USB 2.0
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS
