Phaser 3300MFP Service Manual 9-15
Parts List
10-1 GEAR-PICK UP_INNER —
10-2 GEAR-PICK UP_OUTER —
10-3 SPRING-CS —
11 SHAFT-M_FEED2 —
12 GEAR-FEED2 Z27 —
13 SPRING-ES —
15 ROLLER-FEED ROLLER 1 022N02080
16 GROUND-P-EARTH TR —
17 PMO-LOCKER CST —
18 SPRING-TS —
19 CAM-M-PICK_UP —
20 RING-CS —
21 SOLENOID-HB (MANUAL) —
22 SOLENOID-FEED ROCKY2 —
23 GROUND-P-DRIVE —
24 GROUND-P-PUSH BUSHING —
25 GROUND-P-DRIVE2 —
26 CABLE CLAMP —
27 SPRING ETC-GUIDE DEVE —
28 PMO-PLATE GUIDE DEVE_L —
29 PMO-PLATE GUIDE DEVE_R —
30 GROUND-P-SHIELD —
31 TERMINAL-P_CRUM —
32 HOLDER-BEARING EXIT F/DOWN —
33 MEA RACK-EXIT ROLLER 022N02081
34 ROLLER-EXIT F/DOWN —
35 PBA SUB-TERMINAL —
36 MEA RACK-EXIT ROLLER —
36-1 PMO-ROLLER FD F —
36-2 PMO-ROLLER FD R —
36-3 PMO-HOLDER EXIT ROLL —
36-4 SPRING ETC-EXIT ROLL FD —
39 GROUND-P-FUSER —
40 GROUND-P-MOTOR FUSER —
41 GROUND-P-SHIELD SMPS —
Parts List 6.0 Frame (continued)
ID No. Name/Description
Part Number

Xerox Phaser 3300 Specifications

General

Print Technology	Laser
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Automatic Document Feeder	50 sheets
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Connectivity	USB 2.0
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS
