9-28 Phaser 3300MFP Service Manual

Parts List

1-6 PPR-WHITE BAR SHEET —

1-7 PMO-BUSH —

1-8 ROLLER-EXIT —

1-9 GEAR-AGITATOR-2 —

1-10 RING-C —

1-11 ROLLER-DRIVE —

1-12 SHAFT-M-FEED GEAR 38 —

1-13 PBA SUB-ADF —

1-14 PMO-ACTUATOR SCAN SENSOR —

1-15 SPRING ETC-TORSION DOC (CC2-F) —

1-16 PMO-ACTUATOR REGI SENSOR —

1-17 PMO-ACT EMPTY ADF —

1-18 IPR-GROUND_ROLLER —

1-19 GROUND-P-ADF R2 —

1-20 CBF HARNESS-ADF R GND —

1-21 CBF HARNESS-ADF CLUT1 —

2 ELA HOU-ADF MOTOR 127N07593

2-1 BRACKET-P-GEAR H —

2-2 MOTOR STEP-ADF —

2-3 CBF HARNESS-ADF GND —

2-4 GEAR-IDLE 35 ADF —

2-5 RING-E —

2-6 GEAR-40/21 —

2-7 RING-E —

2-8 GEAR-24 —

2-9 GEAR-40/21 ADF —

2-10 LINK-M_SWING —

2-11 GEAR-SWING 31/20 ADF —

2-12 GEAR-58/25 ADF —

2-13 RING-E —

2-14 IPR-WASHER WAVE —

2-15 GEAR-SWING 31/20 ADF —

2-17 WASHER-PLAIN —

2-18 SHAFT-REGI —

2-19 IMPELLER-ADF —

Parts List 13.0 ADF Assembly (continued)

ID No. Name/Description

Part Number

Brand

Xerox

Model

Phaser 3300
