Phaser 3300MFP Service Manual 9-29

Parts List

2-20 BUSH-6_D —

3 MEA-ADF UPPER 002N02647

3-1 COVER-M_ADF UPPER —

3-2 MEA UNIT-HOLDER ADF 019N00928

3-2-1 HOLDER-M_PAD ADF —

3-2-3 SHEET-ADF HOLDER —

3-2-4 RMO-ADF RUBBER 019N00566

3-2-5 DAMPER-PAD ADF_R2 —

3-3 ROLLER-M-ADF IDLE —

4 MEA UNIT-PICKUP 130N01500

4-1 PMO-COVER ADF —

4-2 GEAR-ADF 38 —

4-3 STOPPER-M_PICKUP ADF —

4-4 SHAFT-ADF PICKUP —

4-5 ICT-PIN ADF —

4-6 WASHER-PLAIN —

4-7 PMO-COVER ADF —

4-8 MEC-PICK UP ROLLER ASSY —

4-8A PMO-SLEEVE PICK UP —

4-8B RMO-PICKUP ROLLER —

4-9 PMO-ADF COLAR —

4-10 SPRING ETC-CLUTCH —

4-11 PMO-ADF CLUTCH —

4-12 GEAR-ADF IDLE 34 —

4-13 PMO-SHAFT PICK UP —

4-14 GEAR-PICK UP 26 —

4-15 PMO-PICK UP CLUTCH SUB —

4-16 MEC-ADF ROLLER ASSY —

4-16A RMO-ADF ROLLER —

4-16B PMO-SLEEVE ADF —

4-17 RING-C —

5 MEA-COVER OPEN 002N02646

5-1 COVER-M_ADF OPEN —

5-2 PMO-GUIDE PAPER —

5-3 DAMPER-PAD ADF_R2 —

Parts List 13.0 ADF Assembly (continued)

ID No. Name/Description

Part Number
