2-30 Phaser 3300MFP Service Manual
Theory of Operation
■ Rated Frequency: 50/60 Hz
■ Frequency Fluctuating range: 47 ~ 63 Hz
■ Input Current: Under 4.0 Arms/2.0 Arms (But, the status when e-coil
is off or rated voltage is inputted/outputted)
■ Rated Output Power
■ Consumption Power
NO ITEM CH1 CH2 Remark
1 CHANNEL NAME +5 V +24.0 V
2 CONNECTOR PIN CON 35 V PIN: 11, 13, 15 GND
PIN: 12, 14, 16
CON 324 V PIN: 3, 5, 7, 9 GND
PIN: 4, 6, 8, 10
3 Rated Output +5 V ± 5% (4.75-5.25 V) +24 V ± 10%
(21.6-26.4 V)
4 Max. Output Current 3 A 4.4 A
5 Peak Loading Current 3.6 A 5.3 A 1 ms
6 RIPPLE NOISE Voltage 100 m Vp-p Under 500 m Vp-p
7 Maximum output 15 W 105.6 W
8 Peak output 18 W 127.2 W 1 ms
9 Protection for loading
shortage and overflowing
current
Shut down or Fuse
Protection
Shut down or Output
Voltage Drop
NO ITEM System
1 Stand-By Less than 150 W
2 PRINTING Less than 400 W
3 Sleep-Mode Less than 11 W

Xerox Phaser 3300 Specifications

General

Print Technology	Laser
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Automatic Document Feeder	50 sheets
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Connectivity	USB 2.0
Maximum Paper Size	8.5 x 14 inches
Operating System Compatibility	Windows, Mac OS
