Xerox WorkCentre 3345 Service Manual

Parts Lists
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
5-16
Parts List 3.1A Frame (2 of 2)
Item Name Part Number
1Duplex Frame Guide -
2 Path Duplex Sheet -
3 Idle Feed M Bush -
4 Bushing Push P Plate -
5 Idle Feed Shaft -
6 Bar Coupling Lever 005N01146
7Clutch Spacer -
8 Feed Roller 022N02673
9 Electric Clutch (Registration Clutch) 121N01219
10 Electric Clutch (Pickup Clutch) 121N01265
11 96 Idle Exit Gear 007N01707
12 65 Exit Gear -
13 Gear BRKT Ground -
14 CST Locker PMO -
15 SAW P Plate -
16 Regi Feed Shaft -
17 Empty Actuator 120N00552
18 Regi Actuator -
19 Feed Actuator -
20 Registration Sensor 130N01574
21 Path EX Duplex Frame -
22 Bottom Frame Plate -
23 SCF M Idle Roller -
24 Harness Cap -
25 Duplex Swing Bracket -
26 23/23 RDCN Gear 35 Feed Actuator 007N01706
27 Exhaust Fan -
28 Shaft -
29 Decurler Roller Frame -
30 Paper BRKT Ground -
31 HVPS Ground -
32 LSU Bracket Ground -
33 HVPS 105N02248
34 Exit Roller Frame -
35 Antistatic Brush -

Xerox WorkCentre 3345 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 600 x 600 dpi
Automatic Document Feeder	50 sheets
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
First Page Out Time (Black)	As fast as 6.5 seconds
Processor	600 MHz
Paper Input (Standard)	250 sheets
Paper Output	150 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Copy Resolution	Up to 600 x 600 dpi
Connectivity	USB, Ethernet, Wi-Fi
Functions	Copy, Print, Scan, Fax, Email
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plugin for Android, Mopria
Media Sizes Supported	Letter, Legal, A4, A5, B5, A6
Fax Transmission Speed	3 seconds per page
Maximum Paper Size	216 x 356 mm
Copy Speed (Black)	Up to 42 cpm
