Xerox WorkCentre 3345 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-17
36 Exit Sensor Holder 130N01669
37 19 DR Swing Gear 007N01705
38 LSU Bracket -
39 RIB TR Guide -
40 Transfer Roller 108R01469
41 Transfer Earth Plate -
42 Rotor Core -
43 TR Terminal -
44 Cable Clamp -
45 Pick Up Roller 130N01673
48 Controller Shield -
49 Rear Door & Bin Full Sensor Harness -
50 Inlet-1 AC Harness -
51 Right LSU Holder BRKT -
52 Left LSU Holder BRKT -
53 Extension Ground BRKT -
54 29 Idle Feed Gear 007N01827
55 Spring-TS 009N01653
56 Gear-Feed 20 022N02672
57 Fan-Type1 (SMPS Fan) 127N07834
