Page #264 background imageLoading...
Page #264 background image
08/2012
5-61
WorkCentre 5021/5019
99.3, 99.4
Parts List
Initial Issue
99.3 Consumables 99.4 Electrical Adjustment
Table 1
Consumables A.C
1 Toner (K) 409K
Table 1
Electrical Adjustment A.C
1 Side Regi Adjustment (Tray 1) 77B1
2 Side Regi Adjustment (Tray 2) 77B2
3 Side Regi Adjustment (MSI) 77B5
4 Lead Regi Adjustment (Tray 1) 77C5
5 Lead Regi Adjustment (Tray 2) 77C6
6 Lead Regi Adjustment (MSI) 77C9
7 White Ref Adjustment 771M
8 IIT Calibration 7726
9 CCD Calibration 77CD
10 Light Axis Fluctuation Correction 77CE
11 ROS Write Timing 77F7
12 Border Erase Adjustment 77B6
13 Calibration 77B7
14 MAX SET UP (Image Quality Adjustment) 7720
15 ATC SENSOR SET UP 77B8
16 TRC Adjustment 77B9
17 ADC/AGC SETUP 77BB
18 Tone UP/DOWN Adjustment 77BC
19 NVM Initialization (IIT/IPS) 702A
20 NVM Initialization (SYS-System) 77BE
21 NVM Initialization (SYS-User) 702D
22 NVM Initialization (IOT) 77BF
23 NVM Initialization (ALL) 77BG
24 Lead Edge Border Erase Adjustment 77BH
25 Trail Edge Border Erase Adjustment 77BJ
26 Side Erase Adjustment 77BK
27 FS R/E Adjustment 77BL
28 SS R/E Adjustment 77BM
29 Temperature Adjustment 7751
30 Fixed R/E Change 77C1
31 Buzzer Level 77C2
32 Download (Reinstall) 77E1
33 Download (Version UP) 77E2
34 Other NVM Changes 7760
35 Other Diag. Adjustment 77BN
36 Auto Gradation Correction 77F1
37 ATC Sensor Setup 77F3
38 Tone Up/Down 77F5
39 Secondary Traansfer Output Adjustment 77F6
