Xerox WorkCentre 5021 Service Documentation

08/2012
3-27
WorkCentre 5021/5019
3.5
Image Quality
Initial Issue
3.5 Cycle Table
*1: This is 50.24/1.86=27 mm because the rotation is at 1.86 times the peripheral speed.
Table 1
Item Module Name Diameter (mm) Pitch (mm)
1 PH Regi Roll 20 63
2 DEVE Mag Roll 16 27*1
13.5 (half-pitch)
3 XERO BCR 12 38
4 DRUM(OPC) 30 94
5 BTR 16 50
6 Fusing Unit Heat Roll 25 79
7 Pressure Roll 30 94
8 Exit Roll 15 47

Xerox WorkCentre 5021 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 20, 000 pages
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Maximum Paper Size	A3
Duplex Printing	Manual
Memory	128 MB
Fax Transmission Speed	33.6 Kbps (optional)
Operating System Compatibility	Windows, Mac
Print Resolution	600 x 600 dpi
