08/2012
6-25
WorkCentre 5021/5019
6.2.1, 6.2.2
General Procedures
Initial Issue
6.2.1 Tools and Service Consumables
6.2.1.1 Tools
Most of the maintenances can be done with standard tools described in the following table:
*: 499T 00353 : STUBBY DRIVER should be used when replacing the ROS ASSEMBLY.
6.2.1.2 Service Consumables
There are no Service Consumables unique to this model.
Whenever special consumables for the machine are required, it will be notified in a separate
technical information.
6.2.2 Consumables
*1: The maximum number of copies should be regarded as only a guide because it depends on
the way to use, the type of document and the density of print.
*2: The maximum number of prints is a reference value under the condition of A4 LEF and sim-
plex printing. Some specific conditions such as paper size, number of copies for a print job, etc.
might cause a serious deterioration of image quality before the time to replace the drum car-
tridge comes.Evaluation : ISO/IEC 19752 Test Standard. Drum Cartridge specification is
applied when the machine is operated under the following condition.
- Paper: A4 LEF - Paper Tray: Tray1- Mode: Simplex print- Job Runlength: 4 Pages/job- Life
distribution: B(50)
Table 1
No. TOOL No. TOOL NAME
1 499T 00247 Test Pattern(Mono A3X1)
2 499T 00283 Test Pattern (A3) for DADF Adjustment
3 499T 00301 Screw Driver(-) 3X50
4 499T 00353 Stubby Driver*
5 499T 00355 Screw Driver(+) 100 mm
6 499T 01423 Box Driver with Magnet(5.5 mm)
7 499T 01901 Side Cutting Nipper
8 499T 02005 Round Nose Plier-Safety
9 499T 02320 S/E TESTER SET
10 499T 02601 Silver Scale 150 mm
11 499T 08104 Flash Light(U-3)
12 499T 08902 Brush
13 499T 09507 TESTER LEAD WIRE (Red)
14 499T 09508 TESTER LEAD WIRE(Black)
Table 1
Consumables Product Code CRU/ERU YieLd / life
Toner Cartridge(9K) CT202037 CRU 9KPV*1
@Declared yield in accordance with
ISO/IEC 19752
Drum Cartridge CT350986 CRU 343Kcycle
@ ISO/IEC 19752 Standard Test Page
<Reference>75KPV*2@18PPM /
80KPV*2@20PPM
