Xerox WorkCentre 5021 Service Documentation

08/2012
6-27
WorkCentre 5021/5019
6.3.1.1
General Procedures
Initial Issue
6.3.1.1 DADF Input Component Check List
Table 1 DADF Input Component Check List
Chain-Link Component Name Connecter Level Description
005-102 DADF DOCUMENT SET SENSOR L L: Document detected at DADF DOCUMENT SET SENSOR
005-110 DADF REGI. SENSOR H H: Document detected at DADF REGI SENSOR
005-206 DADF PRE REGI. SENSOR H H: Document detected at DADF PRE REGI SENSOR
005-211 DADF INVERT SENSOR H H: Document detected at DADF INVERT SENSOR
005-212 DADF INTERLOCK SWITCH L L: FEEDER OPEN SENSOR
005-213 DADF OPEN SENSOR H H: DADF PLATEN INTERLOCK OPEN
005-215 DADF TRAY SET GUIDE SENSOR 1 L L: The Actuator is not blocked.
005-216 DADF TRAY SET GUIDE SENSOR 2 L L: The Actuator is not blocked.
005-217 DADF TRAY SET GUIDE SENSOR 3 L L: The Actuator is not blocked.
005-221 DOCUMENT TRAY SIZE SENSOR 1 L L: Document detected at DOCUMENT TRAY SIZE SENSOR 1
005-222 DOCUMENT TRAY SIZE SENSOR 2 L L: Document detected at DOCUMENT TRAY SIZE SENSOR 2
005-224 SACN START H H: SCAN START signal ON detected
005-228 APS EXIST L L: APS SENSOR detected

Xerox WorkCentre 5021 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 20, 000 pages
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Maximum Paper Size	A3
Duplex Printing	Manual
Memory	128 MB
Fax Transmission Speed	33.6 Kbps (optional)
Operating System Compatibility	Windows, Mac
Print Resolution	600 x 600 dpi
