Xerox WorkCentre 5021 Service Documentation

08/2012
6-29
WorkCentre 5021/5019
6.3.1.3
General Procedures
Initial Issue
6.3.1.3 IOT Input Component Check List
Table 1 IOT Input Component Check List
Chain-Link Component Name Connecter Level Description
071-300 L/H COVER INTERLOCK SWITCH H H: L/H COVER INTERLOCK SWITCH is closed
071-301 FRONT COVER INTERLOCK SWITCH H H: FRONT COVER INTERLOCK SWITCH is closed
072-300 STM LEFT COVER SWITCH L L: STM LEFT COVER SWITCH is closed
072-100 TRAY 1 NO PAPER SENSOR L L: Paper detected at TRAY 1 NO PAPER SENSOR
072-101 TRAY 2 NO PAPER SENSOR L L: Paper detected at TRAY 2 NO PAPER SENSOR
072-102 MSI NO PAPER SENSOR L L: Paper detected at MSI NO PAPER SENSOR
072-103 TRAY 2 NUDGER LEVEL SENSOR H H: TRAY LIFT UP
072-104 TRAY 2 FEED OUT SENSOR L L: Paper detected at TRAY 2 FEED OUT SENSOR
072-105 TRAY 2 PAPER SIZE SWITCH L L: SW 5 of TRAY 2 PAPER SIZE SWITCH is ON
071-105 REGI. SENSOR L L: Paper detected at REGI SENSOR
071-106 FUSING UNIT EXIT SENSOR L L: Paper detected at FUSING UNIT EXIT SENSOR
