6.3.3 Analog Monitor Code List
Table 1 Analog Monitor Code List
Chain-Link Component Name Description
072-050 TRAY 2 PAPER SIZE Sensor Displays the AD value for Tray 2 paper size.
For the relationsip between the Tray 2 paper size and the AD value, refer to 'BSD Chain 7.1' in Chapter 7.
092-050 ATC SENSOR Displays the AD value that was detected by the ATC SENSOR.
• AD Value Retrieval Range: 0~999
• Normal Range: 100~900
• Failure Determination Level: Out of the above range
010-050 Heat Roll STS Center
Temperature at the Center of the Heat Roll
Displays the AD value for the temperature that was detected by the FUSING UNIT CENTER THERMISTOR.
• AD Value Retrieval Range: 0~1023
• Normal Environment: 488 (210 degrees C) to 760 (145 degrees C)
• High Temperature Failure Determination Level: when 362 and lower [245 degrees C and higher] is
detected continuously for the specified time.
010-051 Heat Roll STS Rear
Temperature at the Ends of the Heat Roll
Displays the AD value for the temperature that was detected by the FUSING UNIT REAR THERMISTOR.
• AD Value Retrieval Range: 0~1023
• Normal Environment: 490 (210 degrees C) to 761 (145 degrees C)
• High Temperature Failure Determination Level: when 292 and lower [270 degrees C and higher] is
detected continuously for the specified time.
