Xerox WorkCentre 5021 Service Documentation

08/2012
6-107
WorkCentre 5021/5019
6.4.3
General Procedures
Initial Issue
6.4.3 Error Display during Diag
Overview
• The error displays that may appear when performing the various Diag functions are as fol-
lows.
Table 1
Diag Function Error Display Meaning Remarks
Refer to NVM Err E-2 The Chain-Link # that was input is incorrect/an unused Chain-Link #/for an option that is not installed
Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
NVM Settings Err E-2 The Chain-Link # that was input is incorrect/an unused Chain-Link #/for an option that is not installed
Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
Err E-5 The Chain-Link # that was input is for an item that cannot be changed
Err E-6 The value that was input is out of the valid range
Initialize NVM Err E-2 The Chain-Link # that was input is incorrect/an unused Chain-Link #/for an option that is not installed
Err E-7 Failed to initialize the specified area
Shutdown History Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
Jam Counter Reset Err E-2 The Chain-Link # that was input is incorrect/an unused Chain-Link #/for an option that is not installed
Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
HFSI Counter Reset Err E-2 The Chain-Link # that was input is incorrect/an unused Chain-Link #/for an option that is not installed
Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
Analog Monitor Err E-2 The Chain-Link # that was input is incorrect/an unused Chain-Link #/for an option that is not installed
Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
Component Check Err E-2 The Chain-Link # that was input is incorrect/an unused Chain-Link #/for an option that is not installed
Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
Tone Up/Down Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
ATC Sensor Read Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
READ TEMPERTURE Err E-4 Unable to perform the function as the parts that are the target for the Diag are malfunctioning, etc.
