08/2012
6-109
WorkCentre 5021/5019
6.6
General Procedures
Initial Issue
6.6 KO PROGRAM# LIST
NOTE: For how to enter the System Administrator Mode, refer to [1.2 Service Call Procedure]
in Chapter 1 Service Call Procedure.
Table 1 KO PROGRAM# LIST
Tools
P# Name Min Max Default
Infrequent
Range
Write by
KO Description
100 Energy Saver: Low Power Mode Timer 1 60 1 - O This can also be set to '0' at the DIAGNOSTIC_MODE, which will also
display its Current Value as '0'.
101 Energy Saver: Sleep Mode Timer 1 239 1 - O This can also be set to '0' at the DIAGNOSTIC_MODE, which will also
display its Current Value as '0'. (min)
102 Timer: Auto Clear Timer 0 6 2 - O 0: Return to default display after 15 s
1: Return to default display after 30 s
2: Return to default display after 45 s
3: Return to default display after 1 min
4: Return to default display after 2 min
5: Return to default display after 3 min
6: Return to default display after 4 min
103 Timer: Operating Timer 1 240 10 - O sec
104 Timer: No Next Document Timer 1 4 2 - O 1: Scan Complete in 20 s
2: Scan Complete in 30 s
3: Scan Complete in 60 s
4: Scan Complete in 90 s
105 Timer: Job Cancel Timer - - 600 0, 60~5940 O 0: Feature Disabled (s)
106 Timer: Job End Screen Display Timer 1 10 3 - O sec
202 Report: Report Manual Output Instruction 1 5 1 - O 1: Print the System Setting Report
2: Print the Service Setting Report
3: Print the Job History Report
4: Print the Error History Report
5: Print the Job Counter Report
203 Authentication: Account Mode 0 2 0 - O 0: Account Free Mode
1: Single Account Mode
2: Multi Account Mode
206 Locale Information: Paper Size Group
(WC 5021/5019)
2 5 4 - O 2: XC (NA (North America))
3: XE/DMO-E (EU)
4: AP/GCO (AP)
5: DMO-W (SA (South America))
206 Locale Information: Paper Size Group
(WC 5021/5019)
2 5 3 - O 2: XC (NA (North America))
3: XE/DMO-E (EU)
4: AP/GCO (AP)
5: DMO-W (SA (South America))
To Next Page
