Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 289
UG196 (v1.3) May 25, 2007
DRP Address by Attribute
R
DEC_PCOMMA_DETECT_0
46<4>
DEC_PCOMMA_DETECT_1
1e<7>
DEC_VALID_COMMA_ONLY_0
31<7>
DEC_VALID_COMMA_ONLY_1
1e<8>
MCOMMA_10B_VALUE_0
30<13> 30<14> 30<15>
31<0> 31<1> 31<2> 31<3> 31<4> 31<5> 31<6>
MCOMMA_10B_VALUE_1
1f<2> 1f<1> 1f<0>
1e<15> 1e<14> 1e<13> 1e<12>
1e<11>
1e<10>
1e<9>
MCOMMA_DETECT_0
30<12>
OOB_CLK_DIVIDER
26<14> 26<13> 26<12>
OOBDETECT_THRESHOLD_0
3a<3> 3a<4> 3a<5>
OOBDETECT_THRESHOLD_1
15<12>
15<11>
15<10>
OVERSAMPLE_MODE
26<15>
PCI_EXPRESS_MODE_0
46<15>
PCI_EXPRESS_MODE_1
9<0>
Ta ble D - 2 : DRP Address by Attribute (Continued)
Attribute
Bit
0 1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
