Xilinx Virtex-5 RocketIO GTP User Manual

Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 17
UG196 (v1.3) May 25, 2007
R
Section 1: FPGA Level Design
This section provides the information needed to incorporate RocketIO™ GTP transceivers
into an FPGA design, including:
• The features and characteristics of the GTP transceivers
• How to use the RocketIO GTP Wizard to configure the transceivers
• Mapping of transceiver instances to device resources
• Simulation of GTP transceiver designs
• Board-level clocking and power requirements
This section includes the following chapters:
“Introduction to the RocketIO GTP Transceiver”
“RocketIO GTP Transceiver Wizard”
“Simulation”
“Implementation”
“Tile Features”
“GTP Transmitter (TX)”
“GTP Receiver (RX)”
“Cyclic Redundancy Check (CRC)”
“Loopback”
“GTP-to-Board Interface”
