Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 39
UG196 (v1.3) May 25, 2007
R
Chapter 2
RocketIO GTP Transceiver Wizard
The RocketIO GTP Transceiver Wizard is the preferred tool to generate a wrapper to
instantiate a GTP_DUAL primitive. The Wizard can be found in the Xilinx CORE
Generator tool. Be sure to download the most up-to-date IP Update before using the
Wizard. Details on how to use this wizard can be found in UG188
, RocketIO GTP
Transceiver Wizard User Guide.
1. Start the Xilinx CORE Generator tool.
2. Locate the RocketIO GTP Wizard in the taxonomy tree under:
/FPGA Features & Design/IO Interfaces
See Figure 2-1.
3. Double click RocketIO GTP Wizard to launch the Wizard.
Figure 2-1: Locating the RocketIO GTP Wizard
UG196_c2_01_100406
