Xilinx Virtex-5 RocketIO GTP User Manual

34 www.xilinx.com Virtex-5 RocketIO GTP Transceiver User Guide
UG196 (v1.3) May 25, 2007
Chapter 1: Introduction to the RocketIO GTP Transceiver
R
COMMA_10B_ENABLE_0
COMMA_10B_ENABLE_1
Sets which bits of MCOMMA/PCOMMA
must be matched to incoming data and
which bits are don't cares.
Configurable Comma
Alignment and Detection
(page 151)
COMMA_DOUBLE_0
COMMA_DOUBLE_1
When TRUE, a PCOMMA match followed
immediately by an MCOMMA match is
required for comma detection. Used to
detect A1/A2 framing characters for
SONET.
Configurable Comma
Alignment and Detection
(page 151)
DEC_MCOMMA_DETECT_0
DEC_MCOMMA_DETECT_1
Enables detection of negative 8B/10B
commas.
Configurable 8B/10B Decoder
(page 158)
DEC_PCOMMA_DETECT_0
DEC_PCOMMA_DETECT_1
Enables detection of positive 8B/10B
commas.
Configurable 8B/10B Decoder
(page 158)
DEC_VALID_COMMA_ONLY_0
DEC_VALID_COMMA_ONLY_1
Limits the set of commas to which
RXCHARISCOMMA responds.
Configurable 8B/10B Decoder
(page 158)
MCOMMA_10B_VALUE_0
MCOMMA_10B_VALUE_1
Defines comma minus to raise
RXCOMMADET and align the parallel
data.
Configurable Comma
Alignment and Detection
(page 151)
MCOMMA_DETECT_0
MCOMMA_DETECT_1
Set to TRUE to allow minus comma
detection and alignment.
Configurable Comma
Alignment and Detection
(page 151)
OOB_CLK_DIVIDER Sets the squelch clock rate based on CLKIN.
RX OOB/Beacon Signaling
(page 131)
OOBDETECT_THRESHOLD_0
OOBDETECT_THRESHOLD_1
Sets the minimum differential voltage
between RXN and RXP before a signal is
recognized as a valid PCI electrical idle or a
SATA OOB signal.
RX OOB/Beacon Signaling
(page 131)
OVERSAMPLE_MODE Enables 5X oversampling.
TX Buffering, Phase Alignment,
and Buffer Bypass (page 105),
Parallel In to Serial Out (PISO)
(page 111), Serial In to Parallel
Out (SIPO) (page 141),
Oversampling (page 144),
Configurable RX Elastic Buffer
and Phase Alignment (page 163)
PCI_EXPRESS_MODE_0
PCI_EXPRESS_MODE_1
Enables certain operations specific to PCI
Express.
Power Control (page 82),
Configurable Channel Bonding
(Lane Deskew) (page 178)
PCOMMA_10B_VALUE_0
PCOMMA_10B_VALUE_1
Defines comma plus to raise
RXCOMMADET and align the parallel
data.
Configurable Comma
Alignment and Detection
(page 151)
PCOMMA_DETECT_0
PCOMMA_DETECT_1
Set to TRUE to allow plus comma detection
and alignment.
Configurable Comma
Alignment and Detection
(page 152)
PCS_COM_CFG Shared PLL configuration settings. Shared PMA PLL (page 61)
Table 1-4: GTP_DUAL Attribute Summary (Continued)
Attribute Description Section (Page)
