Xtralis ADPRO FastTrace 2 series User Manual

ADPRO
®
FastTrace™ 2 Series Hardware Installation Manual
21790_05 45
Slot
Type
Extension Card
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
If you want to use a second Extension I/O card, you have to replace either the Ethernet card or one of the
analogue video cards in the PCI Express slots.
Analogue Cameras (16 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 16 channels 1 (DS42xx)
2
PCI Express
Ethernet Card
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Analogue Cameras (20 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 16 channels 1 (DS42xx)
2
PCI Express
A/V 4 channels 1 (DS42xx)
3
PCI Express
Ethernet card
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
If you want to use a second Extension I/O card, you have to replace either the Ethernet card or one of the
analogue video cards in the PCI Express slots.
IP Cameras (Up to 32 Channels* with 1 Ethernet Card)
Slot
Type
Extension Card
1
PCI Express
2
PCI Express
Ethernet Card
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
(*) You can purchase IP camera licenses individually or in sets of 4. Depending on the license(s) you have
purchased, you will have 1-32 video channels available. The full 32 channels are only available on
FastTrace 2E models with XOa firmware installed, an Intel DH61BE or MiTAC PH10LU motherboard, and
4 GB RAM or more. On any other model, maximum 16 IP channels are available.
Note
You can use the Ethernet card only on FastTrace 2E units.
