Xtralis ADPRO FastTrace 2 series User Manual

Hardware Installation Manual ADPRO
®
FastTrace™ 2 Series
44 21790_05
Hybrid (12 Channels with 1 HIPI Card)
Slot
Type
Extension Card
1
PCI Express
A/V 4 channels 1
2
PCI Express
HIPI (ETH1)
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Hybrid (16 Channels with 1 HIPI Card)
Slot
Type
Extension Card
1
PCI Express
A/V 8 channels 1
2
PCI Express
HIPI (ETH1)
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
7.3.4.4 The Xtralis Configurations for FastTrace 2E Units
Analogue Cameras (4 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 4 channels 1 (DS42xx)
2
PCI Express
Ethernet Card
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Analogue Cameras (8 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 8 channels 1 (DS42xx)
2
PCI Express
Ethernet Card
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Analogue Cameras (12 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 4 channels 1 (DS42xx)
2
PCI Express
A/V 8 channels 1 (DS42xx)
3
PCI Express
Ethernet card
