FastTrace™ 2 Series Hardware Installation Manual
21790_05 43
Slot
Type
Extension Card
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Analogue Cameras (8 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 8 channels 1 (DS42xx)
2
PCI Express
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Analogue Cameras (12 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 4 channels 1 (DS42xx)
2
PCI Express
A/V 8 channels 1 (DS42xx)
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
Analogue Cameras (16 Channels)
Slot
Type
Extension Card
1
PCI Express
A/V 16 channels 1 (DS42xx)
2
PCI Express
3
PCI Express
Extension I/O 2
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
IP Cameras (8 or 16 Channels with 1 or 2 HIPI Cards)
Slot
Type
Extension Card
1
PCI Express
Extension I/O 2
2
PCI Express
HIPI (ETH1)
3
PCI Express
HIPI (ETH2) (only when 16 channels)
4
PCI
Main I/O 2
5
/
Extension I/O 1
6
/
Main I/O 1
