Yamaha E40J - Propeller Shaft Housing

LOWR
6-11
6F65G11
Lower unit
Propeller shaft housing
6F66070E
4 N·m (0.4 kgf·m, 3.0 ft·lb)
8 N·m (0.8 kgf·m, 5.8 ft·lb)
No. Part name Q’ty Remarks
1 Lower case cap 1
2 Bolt 9 M6 × 25 mm
3 Seal 1
4 Taper roller bearing assembly 1
5 Forward gear shim —
6 Forward gear 1
7 Shift plunger 1
8 Dog clutch 1
9 Cross pin 1
10 Spring 1
11 Slider 1
12 Spring 1
13 Propeller shaft 1
14 Washer 1
15 Reverse gear 1
16 Reverse gear shim —
17 Ball bearing 1
Not reusable
Not reusable
Not reusable
