6F65G11
1-8
9
8
7
6
5
4
3
2
1
Predelivery checks
Checking the steering system
1. Check the steering friction for proper
adjustment.
NOTE:
9 To increase the friction, turn the friction
adjusting bolt in direction a.
9 To decrease the friction, turn the friction
adjusting bolt in direction b.
2. Check that the steering operates smooth-
ly.
3. Check that there is no interference with
wires or hoses when the outboard motor
is steered.
Checking the gear shift and throttle
operation
1. Check that the gear shift operates
smoothly when the shift lever or remote
control lever is shifted from neutral to for-
ward or reverse.
2. Check that the throttle operates smooth-
ly when the throttle grip (tiller handle
model) is turned from the fully closed
position to the fully open position a.
Check that the throttle operates smooth-
ly when the remote control lever (remote
control model) is shifted from forward or
reverse to the fully open positions a.
