Yamaha E40J - Starter Motor (WH, W)

6F65G11
8-14
9
8
7
6
5
4
3
2
1
Starting system/Starter motor
6F68010E
1.0mm
0.15mm
2.0mm
0.25mm
0.25mm
No. Part name Q’ty Remarks
1 Clip 1
2 Pinion stopper 1
3 Spring 1
4 Pinion assembly 1
5 Bolt 2
6 Housing 1
7 Washer set 1
8 O-ring 1
9 Armature assembly 1
10 Bracket 1
11 Brush holder 1
12 Brush 2
13 Yoke assembly 1
Not reusable
Starter motor (WH, W)
