Yamaha E40J - Assembling the Base Assembly; Disassembling the Base Assembly

6F65G11
5-18
9
8
7
6
5
4
3
2
1
Disassembling the base assembly
1. Remove the O-ring and oil seal.
Assembling the base assembly
1. Apply grease to a new oil seal, then
install it into the base assembly.
2. Install a new O-ring.
Power unit
6F650240
6F650250
1
2
Needle bearing attachment 1:
90890-06654
Driver rod L3 2: 90890-06652
